AquaMatic K524 A125 Composite Valves
Aquamatic Valve
AquaMatic K524 A125 Composite Valves, AquaMatic K524 Composite Valves, AquaMatic Composite Valves 1.5, AquaMatic Valves, AquaMatic A125

 AquaMatic K524 A125 Composite Valves

Untuk informasi harga dan ketersediaan barang hubungi kami  +6281385066789  +62818807696

1.5inch "Y" pattern diaphragm valves
Glass-filled thermoplastic body and cap


AquaMatic Valve K524 A125

·         Body Size: 1-1/2"

·         Valve Options: Normally closed valve, Spring Assist closed

·         Diaphragm/Seal: Buna−N/EP

·         Drilled and Tapped: None

·         Solenoid Options: None

·         Solenoid Features: None


Features :

·         Large Seat opening and high lift-disc for higher flow rates at a lower pressure loss

·         Separate flow and control chambers permit positive closing without springs; and only nominal cost for spring assist opening for low-pressure and self-draining applications

·         Cost-effective solution both in initial cost, as well as lifetime maintenance expenses

·         Separate diaphragm chambers protects the diaphragm from the flow stream, while allowing the valve to be serviced in-line

·         Pre-formed, stress relieved diaphragm minimizes fatigue, maximizes valve responsiveness and diaphragm lifetime

·         All internal parts in contact with media are made of composite materials

·         Can be actuated with either air or water as control fluid

·         Designed for water treatment applications including those requiring acids, caustic and harsh chemicals that would rapidly corrode medtal valves



kami memiliki stock di Ruko SB1/23 Vila Nusa Indah 5 – Cibubur – Jakarta :

·          AquaMatic K524-X200-14000 Composite Valves PN:1070168 With Kit PN:1070208

·          AquaMatic K524-X230-14000 Composite Valves PN: 1070172 With Kit PN:1070208

·          AquaMatic K524-X200-64000 Composite Valves PN:1076578 With Kit PN:1071220

·          AquaMatic K524-X200-54000 Composite Valves PN:1070173 With Kit PN:1070209

·          AquaMatic K524-X232-14000 Composite Valves PN:1071215 With Kit PN:1070208
