Autotrol Logix 263-740 Automatic Filter Head Valve
263-740
Controller
Autotrol Logix 263-740 Automatic Filter Head Valve, Autotrol Logix 263-740, Automatic Filter Head Valve, Autotrol 263-740, Autotrol Logix 263, Autotrol 263, Autotrol, Autotrol Automatic Filter Head Valve
Autotrol Logix 263-740 Automatic Filter Head Valve

Pastikan produk yang anda dapatkan adalah asli dari PFI Watermaker dengan price harga dan kualitas terbaik di Indonesia



 Autotrol  Logix 263-740 Automatic Filter Head Valve

Performance

·         Flow Rates (Valve Only)

·         Service @ 15 psi (1.03 bar) drop  : 25.0 gpm (5.7 m3/h)

·         Backwash @ 25 psi (1.72 bar) drop : 20.0 gpm (4.5 m3/h)



Dimensions

Valve Connections

·         Tank Thread : 2-1/2-inches – 8, male

·         Inlet/Outlet Threads : 1-3/4-inches – 12 UNC-2A male

·         Drain Line : 3/4-inch NPT, male

·         Brine Line : 3/8-inch NPT, male

·         Distributor Tube Diameter  : 1.050 inches (27 mm)

·         Distributor Tube Length  : 1/2 ± 1/2-inches (13 ± 13 mm) above top of tank



Design Specifications/Ratings

·         Valve Body  : Glass-filled thermoplastic – NSF Listed material

·         Rubber Components : Compounded for cold water – NSF Listed material

·         Valve Materials Certification : WQA Gold Seal Certified to ORD 0902 and NSF/ANSI 44 Rated component for material safety

·         Weight (Valve with Control) : 5.34 Ibs (2.42 kg)

·         Recommended Operating Pressure : 20 - 120 psi (1.38 - 8.27 bar)

·         Hydrostatic Test Pressure : 300 psi (20.69 bar)

·         Water Temperature : 35° - 100°F (2° - 38°C)

Ambient Temperature* : 35° - 120°F (2° - 48.9°C)



*Recommend use of outdoor cover for direct sunlight applications.



Electrical

·         Controller Operating Voltage  : 12 Volt – AC (Requires use of Pentair Water®-supplied transformer)

·         Input Supply Frequency : 50 or 60 Hz (Controller configuration dependent)

·         Motor Input Voltage : 12 Volt – AC

·         Controller System Power Consumption : 3 Watts average



740 Time Clock

·         Simple, economic electronic time clock (chronometric)

·         7- or 99-day regeneration setting

·         High efficiency regeneration sequence

·         12-volt operation

·         Filter or conditioner setting in one control

·         Operates 255, 263, 268 with one controller
