GF Signet 5090 Sensor Powered ProPoint Flow Monitor

$ 0.00

GF-5090
Controller
GF Signet 5090 Sensor Powered ProPoint Flow Monitor, Signet 5090, Sensor Powered ProPoint Flow Monitor, Signet 5090 Sensor Flow Monitor, Signet 5090 Flow Monitor, Flow Monitor

GF Signet 5090 Sensor Powered ProPoint Flow Monitor



GF Signet 5090 Sensor Powered ProPoint Flow Monitor



The Signet 5090 Sensor-Powered ProPoint™ Flow Monitor is the simplest and most economical instrument in the Signet offering. It features a balanced-spring meter movement that is powered by the AC output of the Signet 515 Paddlewheel Flow Sensor. No additional power source is required.

This unique system is suitable for a wide range of flow rates. Packaging in an ¼ DIN housing with a NEMA 4X/IP65 front panel, the 5090 is the first choice for simple flow monitoring, even in the most demanding industrial environments.



Fields of Application:

·         Filtration Systems

·         Remote Flow Monitoring

·         Process Cooling Water

·         Distribution Systems

·         HVAC

·         Process Flow Monitoring



Advantages:

·         Sensor-powered flow rate indication up to 60 m (200 ft) from sensor installation

·         Wide flow range: 1 to 20 fps in pipe sizes DN15 to DN900 (½ to 36 in.)

·         Single-point calibration from front panel

·         High visibility analog display

·         Standards:

·         CUL

·         UL

·         China RoHS



Compatible Products:

·         515 Paddlewheel Rotor-X Flow Sensor
