High Flow Filter Cartridges 6.5 x 60 inch
HF6.56
PFI Filter Cartridge
High Flow Filter Cartridges 6.5 x 60 inch, Filter Cartridges 6.5 x 60 inch, High Flow Filter Cartridges, Filter 6.5 x 60 inch, Cartridges 6.5 x 60 inch

High Flow Filter Cartridges 6.5 x 60 inch

Untuk informasi ketersediaan barang dan harga silahkan hubungi 0818807696

Description:

High FLow Series Pleated Filter cartridges have a 6.5 inch/162.5mm large diameter, and is a coreless, single open-ended cartridge with an inside to outside flow pattern. The large diameter with big filter area insures to reduce the number of filter cartridges and the dimension of housing d. The long service life and high flow rate result in low investment and less manpower in many applications



Applications:

Prefiltration of RO and Pretreatment of sea water desalination

Condensate water filtration

API, solvents, and water filtration in BioPharm market

The filtration of bottled water, high fructose, edible oil, soft drinks, and milk.

Paints and coatings, Petrochemical, Refineries

Microelectronics, film, fiber, and resin

Hubungi kami Phn 081385066789 Email : sales@profilterindonesia.com

Specifications for High Flow Series Filter Cartridges

Dimensions

Outside diameter : 6.5” (162.5mm)

Length  :  60” (1538mm)



Material of Construction

Filter Media : Pleated Polypropylene Compound Radial Pleat design maximizes usable media surface area

End Caps : Glass Fiber reinforced Polypropylene

O-Ring Material : Silicone

Support/Drainage : Polypropylene



Performance

Micron Rating :

1μm, 2μm, 5μm, 10μm, 25μm, 40μm, 70μm, 100μm

Max Operating Temperature : 150°F (65°C)



Replace Filter Cartridge PFI HF60PP001A HF60PP002A HF60PP005A HF60PP010A
