Hydranautics ESPA3-7
ESPA3-7
Hydranautics Membrane
Hydranautics ESPA3-7, Hydranautics ESPA3, Hydranautics, ESPA3-7, Hydranautics ESPA3-7 Indonesia, Hydranautics Indonesia

Hydranautics ESPA3-7



A New Generation of ESPA Performance

The growing family of ESPA (Energy-Saving Polyamide) RO membranes continues to meet the ever-increasing demands of the water treatment industry. Users worldwide have made ESPA their first choice for high productivity and salt rejection.

ESPA1, ESPA2, and ESPA3 have long been the industry leaders, with the highest productivity and rejection available, producing up to 14,000 GPD.

Hydranautics’ ESPA4 low energy membrane delivers even greater productivity and rejection, now at operating pressures of less than 100 psi. Enjoy up to 250% greater productivity per membrane area compared with conventional polyamide membranes, at the lowest cost per gallon produced.

There’s an ESPA solution to fit even the most demanding water treatment needs – now with greater performance, productivity and savings.



Test Conditions

  • The stated performance is initial (data taken after 30 minutes of operation), based on the following conditions:
  • NaCl Solution, PPM* 1500
  • Applied Pressure**, psig (MPa) 150 psi (1.05)
  • Operating Temperature, °F (°C) 77° (25°)
  • Permeate Recovery 15%
  • pH Range 6.5-7.0


*ESPA4 NaCl Solution tested at 500 PPM **ESPA4 tested at 100 psig

Application Data

  • Maximum Applied Pressure, psig (MPa) 600 (4.14)
  • Maximum Feed Flow, GPM (m3/h) 4040-16(3.6), 8-inch-75(17.0)
  • Maximum Operating Temperature, °F (°C) 113° (45°)
  • Feedwater pH Range* 3.0-10.0
  • Maximum Feedwater Turbidity, NTU 1.0
  • Maximum Feedwater SDI (15 mins) 5.0
  • Maximum Chlorine Concentration, PPM <0.1
  • Maximum Ratio of Concentrate to Permeate Flow for Any Element 5:1
  • Maximum Pressure Drop for Each Element, psig 10


Hydranautics ESPA3-7
