JNC Cleal CP Cartridge Filter
JNC-CP
JNC Cleal Filter Cartridge
JNC Cleal CP Cartridge Filter, JNC Cleal Cartridge Filter, JNC CP Cartridge Filter, JNC Cartridge Filter, Cleal CP Cartridge Filter, Cleal Cartridge Filter, CP Cartridge Filter, Cartridge Filter

 JNC Cleal CP Cartridge Filter



Self-Bonding Binder-free Cartridge Filter

Material : Polyolefin



Structure

·         Only polyolefin thermally bonded bi-component fibers (ES fibers) are used, and the fiber-to-fiber bond forms a stable porosity.



Advantages

·         The ES fibers uniquely developed and patented by JNC are used, and the fiber-to-fiber bond at each contact point featuring integral rigid thermally bonded construction enables consistent filtration and eliminates pore size variability and media migration.

·         The density graded construction provides long service life.

·         The simple but clean and rigid structure utilizing state-of-the-art fiber technology allows for longer service life and higher throughputs.

·         A rigid filter structure of fused ES fibers in a three dimensional network with a high tolerance for differential pressure is achieved.

·         The diameter of the structural fibers is changed for every grade, and the grades are clearly differentiated from a nominal filtration size of 1μm to 350μm.

·         FDA approved materials are used, enabling clean filtration.



Specifications

Grade

CP-01

CP-03

CP-05

CP-10

CP-25

CP-50

Nominal Rating(μm)

1

3

5

10

25

50



Grade

CP-75

CP-100

CP-125

CP-150

CP-200

CP-350

Nominal Rating(μm)

75

100

125

150

200

350



Size



Grade

01-100

125-200

350

Outside diameter

68mm

65mm

62mm

Inside diameter

30mm

Standard Length

250mm, 500mm, 750mm



JNC Cleal CP Cartridge Filter

Filters for Plating and Circuit Boards

There is no fiber migration in JNC cartridge filters since the materials of construction are thermally bonded in three dimensions. Circuit defects are prevented because JNC filters do not shed fibers, the filters remove particulate contaminants and the filters are compatible with a wide range of chemicals.



Filters for Coating

There is no fiber migration in JNC cartridge filters since raw materials are thermally bonded in three dimensions. Moreover, since raw materials used to make filters can produce defects [craters, fish eyes, etc.], JNC filters do not shed thereby eliminating filter generated defects.



Filters for Drinking Water

There is no fiber migration in JNC cartridge filters since raw materials are thermally bonded in three dimensional fiber matrix. Moreover, the JNC filter process is not a chemical process with associated variability in production. As a result of the automated Chisso manufacturing processes, the filters are consistent and reproducible which translates to high quality filters.



Filters for Electronic Components and Cleaning Fluids

There is no fiber migration in JNC cartridge filters since the filter raw materials are thermally bonded in a three-dimensional fiber matrix. Moreover, since the filters do not shed and can tolerate high pressures, defective circuit boards are reduced.



Filters for Pure Water

There is no fiber migration in JNC cartridge filters since raw materials are thermally bonded in a three dimensional fiber matrix. Moreover, since the filters do not shed and can tolerate high pressures, high purity water is achieved.



We have product JNC Cleal CP Cartridge Filter :

·         CP FILTER

·         CPH FILTER

·         CP2 FILTER

·         BM FILTER

·         POROUSFINE

·         CSW FILTER

·         GF FILTER
