Pleated Polypropylene Filter Cartridges 1 micron
PL1
Pleated Filter Cartridge
Pleated Polypropylene Filter Cartridges 1 micron, Pleated Filter Cartridges 1 micron, Polypropylene Filter Cartridges 1 micron, Filter Cartridges 1 micron

Pleated Polypropylene Filter Cartridges 1 micron

Untuk informasi harga dan stock ketersediaan barang hubungi kami  +6281385066789

·         PFI Pleated Polypropylene elements are 100% polypropylene with a wide selection of gasket and O-ring materials available

·         Polypropylene end caps are thermally bonded to the media packs eliminating any need for adhesives which might react with or contaminate critical process fluids

·         A broad range of efficiencies with beta ratios of 50 to 5000 provides the flexibility to address any application or upset condition.



Applications

·         Post-Filter for drinking water treatment

·         Chemical Processing

·         Food & Beverage

·         Semiconductor

·         Pharmaceuticals

·         Oil Industry



Specifications

·         Micron ratings : 1μm

·         Length :  10", 20", 30", 40"

·         Outside diameter : 69mm

·         End Cap : 222/Flat , 222/Fin, 226/Flat, 226/Fin, DOE

·         Max. Operating Temperature : 80oC @1 bar,support adaptors are recommended for temperature exceeds 50 oC

·         Maximum operating differential pressure : 4.0bar ,normal temperature

·         Maximum operating differential pressure (reverse direction): 2.0bar normal temperature

·         Sterilization temperature time :  5 times, 20 Minute cycles at 120 oC
