Spun Cartridge Filter 1 Micron

Pastikan produk yang anda dapatkan adalah asli dari PFI Watermaker dengan price harga dan kualitas terbaik di Indonesia

PFI Spun Bonded Filter Cartridges are made of 100% polypropylene fibers. These fibers have been carefully spun together to form a true gradient density from outer to inner surface. Spun Bonded Filter Cartridges are available with core and without core version. The superior structure remains integral even under severe operating conditions and is no media migration. Polypropylene fibers are blown continuous on central molded core, without the need for binders, resins or lubricants. Operation unfiltered fluid passes through depth filter matrix, enables the progressive retention of finer particles, providing high efficiency, high dirt retention, and filter life. Fluid flows from outside to inside through filter media. Particulates are held securely in the filter matrix and clean fluid flows to the downstream side of cartridge.

Features

·         100 % Polypropylene for wide chemical compatibility

·         Excellent flow with low pressure drop

·         Excellent flow with low pressure drop

·         High strength & pressure resistance

·         Nominal & absolute filtration rating

·         Free of surfactants, Binders and Adhesives

·         High dirt holding capacity

·         One piece construction up to1016 mm. and more

Technical Specifications

·         Sizes : 10”,20”,30”40” Long

·         Inner Diameter : 25mm , 28 mm ,48 mm

·         Outer Diameter : 64 mm (2.5”) , 114mm (4.5”) , 6” , 8”

·         Micron Rating : 1

Configuration

Double Open Type (DOE Type)

Code 7 (226 O Ring Design)

End Cap Filter :

DOE – Double Open End ( standar 2 ujung masing masing berlubang )

SOE – Single Open End ( ujung sebelah berlubang dan ujung sebelah tertutup )

Jenis SOE ada beberapa macam sebegai berikut

222/Flat dengan ujung terbuka ukuran 222 O-ring ada 2 dan ujung sebelah tertutup rata

222/Fin dengan ujung terbuka ukuran 222 O-ring ada 2 dan ujung sebelah tertutup dengan moncong segitiga atau sering disebut ujung tombak

226/Flat dengan ujung terbuka ukuran 226 O-ring ada 2 dan terdapat slot pengunci putar ke dalam housing filter , dan ujung sebelah filter tertutup rata

226/Fin dengan ujung terbuka ukuran 226 O-ring ada 2 dan terdapat slot pengunci putar ke dalam housing filter, ujung sebelah lagi tertutup dengan moncong segitiga atau sering disebut ujung tombak

Construction

Spun bonded filter cartridges are made up of 100% Polypropylene

Applications

Pharmaceuticals: base product clarifications, membrane pre filter

Fine chemicals: solvents, process streams, water purification

Food & beverages: bottled water, flavors, polishing lines

Petrochemicals: water flood, completion fluids, amines

Water treatment: membrane protection, resin trap

Cosmetics: alcohols, essential oils , water lines

Electronics: electroplating, etching, image development

Metal finishing: plating solution, paint and resin products, wash

Magnetic coating: dispersions, coating lines, solvents
