Wellmate WM80 Pressure Tank 1000 liter
WM80
Wellmate
Wellmate WM80 Pressure Tank 1000 liter, Wellmate Pressure Tank, Pressure Tank, Wellmate WM60 Pressure Tank, Wellmate WM35 Pressure Tank, Wellmate WM23 Pressure Tank, Composite Pressure Tank

 Wellmate Pressure Tank



WM Series

Captive Air and Retention Tanks

Easier to install than steel and tougher over time.

Our WM-Series offers features and benefits steel tanks just can’t match. From their corrosion-proof composite construction... to their lighter weight, easier maintenance and less expensive installation… WM-Series pressure tanks are the preferred choice of professionals.



Features & Benefits

Replaceable air cell assures easier field servicing.

Greater drawdown than comparably sized steel tanks yields greater efficiency.

Extended labor warranty option is available to homeowners.

Won’t rust in corrosive environments, particularly important in coastal regions.

Quicker and less costly to install, usually requiring only one person and fewer man-hours.

Wider pressure setting differential provides greater flexibility.



Applications

Residential

Light commercial

Pressure boosting



Specifications

WM Series Performance Data

Model

Capacity liter

Max. Press. Bar

Dia.* inch / cm

Height* cm

Connect.

Weight*  kg

WM-9

112

8.6

16 / 41

112

1" male NPT

11.2

WM-12

153

8.6

16 / 41

145

1" male NPT

13.6

WM-23

301

8.6

21 / 53

157

1 1/4" male NPT

29.8

WM-35WB

453

8.6

24 / 61

189

1 1/4" male NPT

43.1

WM-60

707

8.6

30 / 76

201

2" Pipe Socket

106.14

WM-80

999

8.6

36 / 91

206

2" Pipe Socket

132.45



Note: Maximum external operating temperature 120°F (49°C). Maximum internal operating temperature 100°F (38°C). Minimum operating temperature 40°F (4°C).

* Diameter, height and weight may vary slightly without notice.

** In keeping with current industry standards, drawdown factors are based on Boyle's law. Actual drawdowns will vary depending upon system variables, including the accuracy and operation of the pressure switch and gauge and operating temperature of the system.
