AquaMatic K524-X232-14000 Composite Valves

Pastikan produk AquaMatic K524-X232-14000 Composite Valves yang anda dapatkan adalah asli dari PFI Watermaker dengan price harga dan kualitas terbaik di Indonesia

1.5inch "Y" pattern diaphragm valves
Glass-filled thermoplastic body and cap

·         Body Size: 1-1/2"

·         Valve Options: Normally closed valve, Spring Assist closed

·         Diaphragm/Seal: Buna−N/EP

·         Drilled and Tapped: None

·         Solenoid Options: None

·         Solenoid Features: None

Features :

·         Large Seat opening and high lift-disc for higher flow rates at a lower pressure loss

·         Separate flow and control chambers permit positive closing without springs; and only nominal cost for spring assist opening for low-pressure and self-draining applications

·         Cost-effective solution both in initial cost, as well as lifetime maintenance expenses

·         Separate diaphragm chambers protects the diaphragm from the flow stream, while allowing the valve to be serviced in-line

·         Pre-formed, stress relieved diaphragm minimizes fatigue, maximizes valve responsiveness and diaphragm lifetime

·         All internal parts in contact with media are made of composite materials

·         Can be actuated with either air or water as control fluid

·         Designed for water treatment applications including those requiring acids, caustic and harsh chemicals that would rapidly corrode medtal valves
