GF Signet Magmeter Flow Sensor
GFSMFS
GF Signet Sensor Monitor
GF Signet Magmeter Flow Sensor, GF Signet, GF Signet Flow Sensor, Magmeter Flow Sensor
GF Signet Magmeter Flow Sensor

Kami adalah importir distributor agen dan supplier terlengkap untuk menyediakan berbagai kebutuhan spare part water treatment untuk keperluan industri dengan price harga terbaik



Description GF Signet Magmeter Sensor

GF Signet Magmeters are versatile, easy-to-install sensors with no moving parts and patented Magmeter technology.

Design provides easier installation and removal than full-line magmeters. Corrosion-resistant materials are available for various applications.



Specification

Flow 3-2551-P0-11

Installs into pipe sizes: DN15 to DN900, 0.5 to 36 in

Operating range: 0.05 to 10 m/s, 0.15 to 33 ft/s

Max Pressure rating: PP 10.3 bar @ 25 °C, 150 psi @ 77 °F

Power Source:

Frequency: 5 to 24 VDC, 15 mA max.

Digital (S³L): 5 to 6.5 VDC, 15 mA max.

Compatibility: 8900, 9900, 9900-1BC, 9950

*Only Signet installation fittings

Standard: FKM O-rings (EPDM or FFKM on request)

Fits Various Pipe Sizes

Magmeters can be installed in pipes ranging from DN15 to DN2550 (0.5 to 102 in.). Fluid diagnostics via LED indicators help with troubleshooting. Bi-directional span capability in 4 to 20 mA version. Selected models are NSF and Lloyds Register-approved. A configuration tool is available for OEM.

Corrosion-resistant materials

Sensors are available in corrosion-resistant materials including PP, PVDF with SS, Hastelloy-C, Titanium options and Stainless Steel to provide long-term reliability with minimal maintenance costs.

Empty pipe detection

An additional benefit is the empty pipe detection, which features a zero flow output when the sensors are not completely wetted.

Output options

Three output options are available: 4 to 20 mA, Frequency and Digital (S³L). Relay Output is d in the 2551 Display version.





Untuk permintaan penawaran GF Signet Magmeter Flow Sensor silahkan hubungi



PT PROFILTER INDONESIA

Ruko Blok G/54 – Gudang A/01

Jl.Canadian Broadway

Kawasan Pergudangan Commpark – Kotawisata – Cibubur

Mobile : 081385066789

Email : sales@profilterindonesia.com
