HFPP Pentair Big Blue Housing Filter Cartridge

LASERKU INDONESIA  adalah perusahaan importir dan agent spare part water treatment dengan stock HFPP Pentair Big Blue Housing Filter Cartridge terlengkap harga serta jaminan kualitas terbaik.

Overview Pentair Big Blue Housing Filter Cartridge

Pentair Big Blue and Big Black Heavy Duty Filter Housings offer the versatility to meet all of your large-capacity filtration needs, including highflow and heavy-sediment applications. The extra large housing allows for greater cartridge capacity, reducing the number of vessels d for high flow-rate applications. Sumps are available in both 10" and 20" lengths. The High-Flow Polypropylene (HFPP) cap is available with 3/4", 1" or 1-1/2" NPT inlet and outlet ports. The 1-1/2" internal port allows a greater volume of liquid to pass through the HFPP cap more rapidly. Big Blue and Big Black Housings are compatible with a broad range of chemicals and are available with or without a pressure relief button. They accept a wide variety of 4-1/2" diameter cartridges.

Features And Benefits

• Available in 10" and 20" lengths
• Available with a pressure relief button on inlet side of cap
• Available with 3/4", 1" or 1-1/2" NPT inlet and outlet ports
• Accepts up to 4-1/2" diameter cartridges
• Large capacity housing suitable for high flow applications

Specifications

• Housing : Polypropylene
• Cap : Polypropylene (HFPP)
• Button Assembly : 300-Series stainless steel, EPDM, and polypropylene
• O-Ring : EPDM
• Temperature Rating : 40-100 oF (4.4-37.8 oC)
• Maximum Pressure
  • 10": 100 psi (6.9 bar)
  • 20" : 90 psi (6.2 bar)
• Initial ∆P (PSI) @ Flow Rate (GPM)
• 1" #10 Big Blue Black/Blue HFPP w/PR
  • 1 psi @ 15 gpm ( 0.07 bar @ 57 Lpm)
• 1" #20 Big Blue Black/Black HFPP w/PR
  • 1 psi @ 15 gpm ( 0.07 bar @ 57 Lpm)
• 1-1/2" #20 Big Blue Black/Blue HFPP w/PR
  • 1 psi @ 20 gpm ( 0.07 bar @ 76 Lpm)
• Maximum Dimensions
• 1" #10 Big Blue Black/Blue HFPP w/PR
  • 30" x 7.45" (338 x 189 mm)
• 1" #20 Big Blue Black/Blue HFPP w/PR
  • 22" x 7.45" (590 x 189 mm)

Untuk informasi lengkap tentang produk , stock dan permintaan penawaran harga Pentair Big Blue Housing Filter Cartridge silahkan hubungi CS kantor kami.
